Cabin Binding Machine
Edge binding for car cabin filters & air cleaning filter packsSpecification
| Use | Edge Binding for Cabin Filters Production |
| Control System | PLC + Touch Screen |
| Media | Synthetic Fibers |
| Electricity | 220V *3P *1/2HP |
| Available Media Width | 80-300 mm |
| Available Pleat Length | 100-500 mm |
| Air Pressure | 6 kgf/㎠ |
| Index Driver | Rotary Cam Type |
Model No. |
Available Media Width |
Available Pleat Height | Operation Speed |
Input |
Hotmelt Applicator | ||
Tank Volume |
Auto Gun Quantity |
Temperature | |||||
| SCB0500NNS | 450 mm | 20-50 mm | 3-4 pcs/min | 10.32 kW | 30 kg * 2 | 2 unit | 30-230 ℃ |
Features
